Choose 5mm Film Faced Plywood and Boost Your Innovation

Choose 5mm Film Faced Plywood and Boost Your Innovation

With its unique features and advantages, our 5mm film-faced plywood sets itself apart from competitors in the market. We prioritize quality and durability, ensuring that our plywood meets and exceeds industry standards. Its versatility makes it suitable for a wide range of construction projects, providing you with a versatile and reliable building material.

Product Detail

cheapest 4x8 plywood

5mm film-faced plywood refers to a type of plywood that is commonly used in construction and woodworking projects. Plywood is a sheet material made by bonding together multiple thin layers or veneers of wood with adhesive. Film-faced plywood is a specific variant where the surface of the plywood is covered with a protective film or coating.



ROCPLEX 5mm Film-Faced Plywood Technical characteristics

Sr No. Property Unit Test Method Value Of Test Result
1 Moisture Content % EN 322 7.5 Check out
2 Density kg/m3 EN 323 690 Check out
3 Bonding Quality Bonding Quality Mpa EN 314 1.68-0.81 Check out
4 Bonding Quality Damage Rate % EN 314 85% Check out
5 Bending Modulus of Elasticity Longitudinal Mpa EN 310 6997 Check out
6 Bending Modulus of Elasticity Lateral Mpa EN 310 6090 Check out
7 Longitudinal Mpa EN 310 59 Check out
8 Lateral Mpa EN 310 43.77 Check out
9 Cycle Life About 15-25 Repeated Using Times According To Projects By Formwork Application


Key features about 5mm film-faced plywood:
  1. Thickness: The “5mm” in “5mm film-faced plywood” refers to the thickness of the plywood panel. It means that the plywood sheet is approximately 5 millimeters thick.
  2. Film Facing: The term “film-faced” indicates that the surface of the plywood is covered with a film or coating, often made of materials like phenolic resin or melamine. This film provides several benefits, including enhanced durability, moisture resistance, and a smoother finish.
  3. Usage: Film-faced plywood is commonly used in construction and woodworking projects where a smooth and durable surface is required. It is often used for creating concrete formwork, especially in situations where the concrete will be poured against the plywood surface. The film facing helps prevent the concrete from sticking to the plywood and makes it easier to remove the formwork once the concrete has set.
  4. Water Resistance: The film facing on the plywood provides a level of water resistance, which is beneficial when the plywood is exposed to moisture during construction or other applications.
  5. Reusability: Film-faced plywood is designed to be reusable, particularly in formwork applications. The film facing helps prolong the life of the plywood by protecting it from wear and tear.
  6. Varieties: Film-faced plywood comes in various grades and qualities. Higher grades tend to have a smoother and more consistent finish, while lower grades might have more imperfections in the film facing.
  7. Availability: Film-faced plywood is available in different sizes and thicknesses, including 5mm, to suit various construction and woodworking needs.



ROCPLEX Brown Film Faced Plywood Save Time, Labor, and Cost

ROCPLEX Film faced plywood Save cost

Be special for phenolic glue and film

The film-faced plywood can be disassembled and used repeatedly for both faces, saving 25% of the cost.

Optimization for the special grade of core

Be special for adhesive

ROCPLEX Film faced plywood Shorten the duration

Excellent effect of de-molding

Shorten 30% of the duration.

Avoid the reconstruction of the wall

Be easy to incise and blend

ROCPLEX Film faced plywood the high-quality casting

The flat and smooth faces

The faces are flat and smooth, avoiding bleeding out remains of bubbles and concrete.

The structure of waterproof and breathability

The edges are polished carefully



ROCPLEX Brown Film Faced Plywood Packing and Loading

cheapest 4x8 plywood

Container Type



Gross Weight

Net Weight

20 GP

8 pallets

22 CBM



40 HQ

18 pallets

53 CBM






ROCPLEX Brown Film-Faced Plywood

Choose ROCPLEX’s 5mm film-faced plywood for your construction needs and experience the benefits of a high-quality and cost-effective solution. Trust in our product to deliver exceptional performance and durability, ensuring successful construction applications.



cheapest 4x8 plywood
film faced plywood| construction plywood| shuttering plywood| formply| formwork plywood| 18mm film faced plywood| film faced plywood price| construction plywood price| shuttering plywood price| formply price| formwork plywood price| film faced plywood whosale| construction plywood whosale| shuttering plywood whosale| formply whosale| formwork plywood whosale| film faced plywood factory| construction plywood factory| shuttering plywood factory| formply factory| formwork plywood factory

Brown Film Faced Plywood 5mm FAQ

Q: What is Brown Film-Faced Plywood?

A: Brown Film Faced Plywood is a type of plywood that has a brown film overlay on both sides, which provides a smooth and durable surface. This type of plywood is commonly used in construction and building projects, such as in formwork, roofing, and flooring.

Q: What are the dimensions of Brown Film Faced Plywood 5mm?

A: Brown Film Faced Plywood typically comes in standard sizes of 1220mm x 2440mm (4′ x 8′).

Q: What is the thickness tolerance of Brown Film Faced Plywood 5mm?

A: The thickness tolerance for Brown Film Faced Plywood is usually +/- 0.3mm.

Q: What is the weight of Brown Film Faced Plywood?

A: The weight of Brown Film Faced Plywood can vary depending on the specific type and manufacturer. However, on average, it weighs approximately 0.50kg per square meter.

Q: What is the moisture content of Brown Film Faced Plywood?

A: The moisture content of Brown Film Faced Plywood should be between 8% to 12% to ensure durability and stability.
